Mesh Generation#

The starting point was the Spline Container.
This component lets you create splines within the editor, and contains the Spline object.
Using Spline.Evaluate we can get the point’s: position, tangent, and up vector.

Before	After

I will eventually create the logic to carve out the terrain, but that will be a biiig project as I would like to make it somehow work outside of the terrain.
i.e. when you make changes to the spline water it won’t keep the old carvings, and when you edit the terrain it doesn’t get in the way of the spline water.
Lots to think about… potentially even a custom Terrain script 😵‍💫😭.

Quad Generation#

The order of vertices	Example of the generated mesh

The order of the vertices don’t matter, as long as they’re clockwise (and make a triangle ofc).

private void AddQuad(float x, float y)
{
    // Addition of vertices matter!
    // Make sure it's clockwise!

    // Triangle 1
    AddTriVertex(x + 1f, y); // C
    AddTriVertex(x, y + 1f); // B
    AddTriVertex(x, y); // A

    // Triangle 2
    AddTriVertex(x + 1f, y); // C
    AddTriVertex(x + 1f, y + 1f); // D
    AddTriVertex(x, y + 1f); // B

    // That concludes our quad
}

200
private void AddTriVertex(float x, float y)
201
{
35 collapsed lines
202
    _spline.Evaluate((float)y / _numberOfVerticesAlongSpline, out float3 position, out float3 tangent, out float3 upVector);
203
    position = transform.InverseTransformPoint(position); // We need to get it in local space
204
    Quaternion rotation = Quaternion.LookRotation(tangent, upVector); // Get the rotation of the point
205
    Vector3 offset = rotation * Vector3.left * (x * (width / _numberOfVerticesPerWidth)); // Use the rotation to set the width position
206
    Vector3 pos = (Vector3)position + offset; // Final position
207
    float scaling = 1f; // TODO scaling based on steepness, this will make waterfalls move faster and stretch
208

209
    // If the vertex exists, then assign the triangle point to the vertex's index
210
    if (vertices.Contains(pos))
211
    {
212
        triangles.Add(vertices.IndexOf(pos));
213
    }
214
    // Add the data to all the channels
215
    else
216
    {
217
        triangles.Add(vertices.Count);
218
        vertices.Add(pos);
219

220
        // Scale UV
221
        Vector4 UV = new Vector4(x, y);
222
        UV.x *= (width / _numberOfVerticesPerWidth); // World space width
223
        UV.y /= (_numberOfVerticesAlongSpline); // Normalise to 0-1
224

225
        float length = _spline.Spline.GetLength() * scaling; // World space length * scaling
226
        UV.y *= length;
227

228
        // Reverse the UV...
229
        if (reverseUV)
230
        {
231
            UV.x = -UV.x;
232
            UV.y = length - UV.y;
233
        }
234

235
        uv.Add(UV);
236
    }
237
}

public override void OnInspectorGUI()
{
    SplineWater splineWater = target as SplineWater;

    EditorGUI.BeginChangeCheck();
    base.OnInspectorGUI();
    if (EditorGUI.EndChangeCheck())
    {
        EditorGUI.BeginChangeCheck();
        splineWater.GenerateLODs();
        splineWater.Spline.changed -= OnSplineChanged;
        splineWater.Spline.changed += OnSplineChanged;
        if (EditorGUI.EndChangeCheck())
        {
            EditorUtility.SetDirty(splineWater);
            EditorSceneManager.MarkSceneDirty(splineWater.gameObject.scene);
        }
    }
}

207
float scaling = 1f; // TODO scaling based on steepness, this will make waterfalls move faster and stretch
208

209
// Merge tri if closed
210
if (_spline.Spline.Closed)
211
{
212
    y = y % _numberOfVerticesAlongSpline;
213
}
214

215
// If the vertex exists, then assign the triangle point to the vertex's index
216
if (vertices.Contains(pos))
217
{
218
    triangles.Add(vertices.IndexOf(pos));
219
}

World Depth#

I followed this post https://ameye.dev/notes/stylized-water-shader/ to learn some water shading methods, and I’m happy I did some research to find this resource as they have the BEST depth logic I’ve ever seen for Unity.

Look how nice it looks!

There is an issue with non-y-flat surfaces, but I’ll go through that in the next section.

Any steep angle above the camera view has this awful artefact that is way too harsh and would be very distracting, so I needed to fix it. (Any surface above the camera will have this issue, but it’s only visible when it’s angled)

World Depth Normal Fix#

Their Depth Fade node uses a more sophisticated method than just the scene depth; however, the logic was flawed as it only supported flat surfaces on the y plane.
In order to get it working at steep angles I used this Quaternion shader functions that I found on Github. Thanks Mattatz!

Simply by rotating the… position?

Tbh I kinda js placed this rotation fix after each position node to find which one it needed to be in, I don’t really understand this shader 💀.

Inside the Depth Fade node, add the nodes in the Normal Fix area.

In order to get the quaternion functions to work in ShaderGraph, we need to make proper functions for them.
You can place the following functions underneath the original from_to_rotation function.

void from_to_rotation_float(float3 v1, float3 v2, out float4 o)
{
  o = from_to_rotation(v1, v2);
}

void from_to_rotation_half(float3 v1, float3 v2, out half4 o)
{
  o = from_to_rotation(v1, v2);
}

And the following underneath the rotate_vector function (the function with float4 r, not float3 r !!!).

void rotate_vector_float(float3 v, float4 r, out float3 o)
{
  o = rotate_vector(v, r);
}

void rotate_vector_half(float3 v, float4 r, out half3 o)
{
  o = rotate_vector(v, r);
}

In order to use the functions within ShaderGraph, you need the Custom Function node.
First add a Custom Function node, then match the following values:

After all this, you can see the labour of our work below!

Before fix	After fix

Refraction Fix#

NOTE

You may have to zoom in to see the difference on smaller devices

Without the fix you can see warping on the arm, even though it’s out of the water.	Now anything out of the water will not refract, and I haven’t found any issues yet so this screen-space solution might work properly!

I needed a function to get the world position based on the depth texture for sampling the HAZE fog volume asset I bought.
This was because I wanted to get the fog colour underneath the water, not on the water (so you can see through the water and get proper fog).
And coincidentally I needed it here too! So I already had the nodes ready.

Thanks to bgolus on the Unity forums I was able to convert depth to world position.
My subgraph looks like this:

WARNING

Make sure to enable Custom Binding on the UV property in order for Branch on Input Connection to work.

Below is how I used it in the water shader.
The green input is just the altered screen space UV from the noise / refraction.
The Split node is basically just the depth difference from the camera.

Steepness#

I wanted to have the river squash and stretch based on the steepness, and the steepness direction.
This took me quite a while to figure out.
I initially wanted to have the steepness be figured without needing to step through the spline, and while it might be possible I decided to precompute the UVs instead.

private void CalculateUVReferenceList()
{
    // Clear
    scaledUVs.Clear();
    steepness.Clear();

    // Starting position
    float currentUVPosition = 0f;

    // Precompute some values
    float splineLength = _spline.Spline.GetLength();
    float stepSize = splineLength / (float)_numberOfVerticesAlongSpline;

    float3 position;
    float3 tangent;
    float3 upVector;
    Vector3 forward;
    // Todo, average out scale over a distance
    for (int y = 0; y < _numberOfVerticesAlongSpline + 1; y++)
    {
        int index = y;

        scaledUVs.Add(currentUVPosition); // Add the current position

        // Tangent is the forward direction, so we don't need to do anything extra
        _spline.Evaluate((float)index / _numberOfVerticesAlongSpline, out position, out tangent, out upVector);
        forward = Vector3.Normalize(tangent);
        if (reverseUV)
        {
            forward = -forward;
        }

        float multiplier = Vector3.Dot(forward, Vector3.up);
        bool isGoingDownhill = multiplier > 0f;
        if (isGoingDownhill)
        {
            multiplier = Mathf.Pow(multiplier, power);
            currentUVPosition += Mathf.Lerp(flatScale, downhillScale, multiplier) * stepSize;
            steepness.Add(Mathf.Lerp(0f, -1f, multiplier)); // Downhill is negative
        }
        else
        {
            multiplier = Vector3.Dot(-forward, Vector3.up);
            multiplier = Mathf.Pow(multiplier, power);
            currentUVPosition += Mathf.Lerp(flatScale, uphillScale, multiplier) * stepSize;
            steepness.Add(Mathf.Lerp(0f, 1f, multiplier)); // Uphill is positive
        }
    }
}

I also wanted to have access of the steepness within the shader, so I packed it into the UV2 channel.
This also controls how much foam should be present.
The steepness is shown below where green is downhill, and blue is uphill.

NOTE

When passing through the UVs, use SetUVs()!

Normal shading It’s hard to see here, but the foam and ripples are stretched.	Debug shading You can see the downhill sections are in green, and the checkerboard pattern is stretched.

This is with exaggerated steepness	And here is the debug

Gerstner UV#

As the UVs are now stretched, so are the Gerstner waves. So I moved the original UVs into the UV3 channel, so we can have both the scaled and unscaled UVs.

Below are the differences:

NOTE

I used the exaggerated steepness and ramped up the Gerstner waves for demonstration
Both use the same steepness, but the unscaled one does not follow the texture UV

Scaled	Unscaled

Foam#

The biggest difference is the foam.

First, I needed a texture.

This is the image I decided to go with. Photo by Jorge Vasconez on Unsplash	In order to use this texture I made you NEED to give proper attribution to the original artist!! Photo by Jorge Vasconez on Unsplash👈

Then I made two texture samples. They both go the same direction down the river, but they move against each other in the perpendicular direction.
I also mirrored one side, and added 0.5 to the y direction on the UV so it isn’t an obvious mirror!

The shader!

A gif of the output for reference.

I think it’s coming out quite nicely, and I cannot wait to use this in a level. This gif is using the full foam, normally the foam is determined by the steepness and edges. (I have also added an offset just in case I need the foam to always show).

Colour#

I added in water colour, so now the depth and surface colours can be set. It can also be controller by a gradient on the SplineWater.
The ColourDepth setting controls the cloudiness of the water, which can also be controlled by the depth gradient through the alpha channel.

Caustics#

I ADDED CAUSTICS
This mf took me a while to implement, but it turns out that was cs I had an interpolation node the wrong way around and didn’t notice for like an hour 💀.

The complicated part was adding it to the existing framework, but the creation itself is quite simple.

We sample a Voronoi three times, one red, one green, one blue.
Then we spread them by a distance, red in one direction and blue in the other.
I am using a 3D Voronoi thanks to Invertex!

NOTE

You can sample them as many times as you want, but it comes at a pretty bad cost as Voronoi is expensive.
You might do better generating a Voronoi texture beforehand, to save on computation.
As I am using 3D Voronoi I would need to create a 3D Texture.
I might do this in the future as I want this to run on the Steam Deck.

In order to have the caustics be projected on the ground, we need to reuse the Depth World Position subgraph.

The Y Offset is to move through the 3D Voronoi. I also decided to pixelate the world position as I wanted it to match the game’s aesthetic.

The caustic colour output.

Multiplied by the scene colour.

Altogether.

The final product will be more subtle, but that’s all customisable.
The best part is that the caustics are occluded by the water colour and foam.

This is the full caustic part of the shader. My apologies for the quality, it’s quite a big section.

The full shader is getting quite large lmao.
